InBio460 4-Door Access Control System

InBio460 4-Door Door Access Control System

The InBio460 4-Door Access Control System is a security solution designed to manage and restrict entry to four different doors within a building or facility.

Features Control Interface For Configuring User Access, Monitoring Entry Logs, and Setting Security Policies

Ideal security solution for offices, commercial buildings, data centers, and high-security areas.

Key Components

• • Access Control Panel – Central controller that manages access permissions and processes entry requests.
  • Card Readers (RFID/Biometric/Keypad) – Devices installed at each door to read credentials (keycards, PINs, or biometrics).
  • Electric Door Locks – Magnetic locks or electric strike locks that physically secure the doors and unlock when authorized access is granted.
  • Exit Buttons/Sensors – Used to release the door from the inside for easy exit.
  • Power Supply Unit (PSU) & Backup Battery – Provides power to the entire system, ensuring functionality during power outages.
  • Software/Management System – A control interface for configuring user access, monitoring entry logs, and setting security policies.
  • Network Connectivity – Support TCP/IP connectivity for remote management.

Functionality

• • User Authentication: Allows entry using RFID cards, PIN codes, fingerprints, or facial recognition.
  • Multi-Door Management: Controls access to four doors independently.
  • Time-Based Access: Restricts access to specific times and days for employees or visitors.
  • Audit Logs & Reports: Tracks and records entry and exit activities for security audits.
  • Alarm Integration: Can be connected to alarms to trigger alerts in case of unauthorized access attempts.
  • Remote Control & Monitoring: Support remote management over LAN with web interface.

Device Specification

• • Number of Doors Controlled: 4 Doors
  • CPU: 32 bit 400MHz CPU
  • Power: 9.6V-14.4V DC
  • Communication: TCP/IP
  • Card holders Capacity: 30000
  • Log Events Capacity: 100000
  • Fingerprint Capacity: 3000
  • Types of Readers Supported: 26-bit Wiegand and RS485 FR Series Reader
  • Number of Readers Supported: 12 (8 RS-485 Reader, 4 26-bit wiegand reader)
  • Package Dimension: 350(L)*90(H)*300(W)mm

Application Scope

• • Office buildings with restricted areas.
  • Warehouses needing controlled access to different sections.
  • Hospitals and labs requiring secure entry for authorized personnel.
  • Educational institutions for securing faculty offices and IT rooms.

Got Application Customization Questions?

• • Chat With One Of Our Qualified Agents online between the hours of 9:00Am – 5:00Pm CST
  • Email our Sales Department to get an answer within 24-hours
  • Contact Sales By Phone between the hours of 9:00Am – 5:00Pm to get instant recommendation

Included Items & Accessories

• • 1 Electric Strike
  • Mounting Tabs
  • Mounting Screws
  • Instructions & Manuals

Manufacturer Warranty

• • 1 Year System & Harware Limited Warranty
