8MP Dual-Lens Two-Way Audio IP Surveillance Camera

8MP Dual-Lens Dual-Light Bullet IP Camera – 180° Wide-Angle 4K Ultra HD, Smart AI Detection, Three Lighting Modes, and Two-Way Audio

The W738AD 8MP Dual-Lens Two-Way Audio IP Surveillance Camera delivers panoramic 180° wide-angle surveillance with dual-lens technology for enhanced detail and coverage. With a 1/2.7″ CMOS sensor, the camera outputs 4K Ultra HD (4096 × 1944P, 19:9 aspect ratio) for sharp, wide-format video ideal for parking lots, building perimeters, entrances, and large open spaces.

Featuring advanced AI-powered analytics, it supports face detection, human & vehicle classification, line crossing, area intrusion, and perimeter protection, making it an intelligent solution for proactive security monitoring. Vehicle detection is supported within a 2–20m range, enhancing traffic and gate control applications.

Features Dual-Lens Technology – Equipped with two lenses for a wider field of view, reducing blind spots and enhancing surveillance accuracy

The camera is equipped with a dual-light system that combines 3 IR array LEDs and 2 warm white LEDs, offering 25–30m infrared and white light range. It supports three lighting modes:

• • Smart Dual Light Mode – IR remains on, and warm light activates when human/vehicle detection is triggered.
  • Pure Infrared Mode – Only IR for discreet night monitoring.
  • Pure White Light Mode – Continuous warm light for full-color night imaging.

With two 2.8mm F1.6 fixed lenses, the camera ensures ultra-wide coverage and rich detail, while built-in two-way audio (microphone & speaker) enables live communication and intruder deterrence. Audio/visual alarms include voice sirens, light flashing, and snapshot recording.

Connectivity and compatibility are ensured with RTSP and ONVIF 23.12 support, H.265/H.264 dual-stream encoding, and P2P cloud service. Remote access is available via multi-browser support, PC client, and mobile apps (iOS/Android). Local storage is supported with a MicroSD slot up to 512GB.

Built in a rugged IP67-rated housing with 4000V lightning protection, the camera is engineered for all-weather outdoor use. Power is provided via PoE IEEE802.3af or 12VDC, with low power consumption (<10W).

Key Features

• • Ultra-Wide 180° Coverage: Dual-lens design with 8MP 4K (4096 × 1944P) panoramic resolution.
  • AI Smart Analytics: Face detection, human & vehicle detection, line crossing, intrusion, perimeter protection.
  • Vehicle Detection Range: 2–20 meters.
  • Lighting System:
    • 3 IR Array LEDs (25–30m)
    • 2 Warm White LEDs (25–30m)
    • Three Modes: Smart Dual Light, Pure IR, Pure White Light
  • Dual Fixed Lenses: 2 × 2.8mm F1.6 for wide panoramic field of view.
  • Two-Way Audio: Built-in microphone & speaker for communication and deterrence.
  • Smart Alarms: Flashing lights, voice siren, snapshot, relay, email/FTP/NAS storage.
  • Compression & Streaming: H.265/H.264 dual-stream for efficient bandwidth.
  • Remote Access: Web (IE/Chrome/Firefox/Edge/Safari), PC client, mobile app (iOS/Android).
  • Local Storage: MicroSD slot up to 512GB.
  • Rugged Outdoor Build: IP67 weatherproof housing with 4000V lightning protection.
  • Flexible Power: IEEE802.3af PoE or 12VDC ±10%.
  • Low Power Consumption: <10W.
  • Operating Conditions: -20°C to +60°C, 10–90% RH.

Device Specification

• • Image Sensor: 1/2.7″ CMOS
  • Resolution: 8MP (4096 × 1944P, 19:9 aspect ratio)
  • Lens: Dual 2.8mm F1.6 fixed lenses
  • Field of View: 180° panoramic wide-angle
  • Illumination: 0.01 Lux (low light), 0 Lux with IR
  • IR/Warm Light:
    • 3 × IR LEDs (25–30m IR distance)
    • 2 × Warm LEDs (25–30m white light distance)
  • Light Modes: Smart Dual Light / Pure Infrared / Pure White Light
  • AI Analytics: Face detection, human & vehicle detection, line crossing, area intrusion, perimeter protection
  • Vehicle Detection: 2–20m range
  • Video Compression: H.265 / H.264 dual-stream
  • Frame Rates:
    • Mainstream: 20fps@8MP, 30fps@6MP/5MP/4MP/3MP/1080P/720P
    • Sub-stream: 30fps@D1/VGA/QVGA
  • Audio: Two-way audio (mic & speaker), G.711u/a, AAC, PCM, AEC audio noise reduction
  • Alarms: Audio/visual alarms, snapshots, relay, email, FTP, NAS storage
  • Interfaces: 1 × RJ45 (100Mbps), 1 × Alarm-in/Alarm-out (optional NO/NC)
  • Protocols: ONVIF 23.12, RTSP, HTTP/HTTPS, FTP, SMTP, DHCP, NTP, RTP, RTMP, IPv4/IPv6, P2P
  • Storage: MicroSD card slot (up to 512GB), NVR, NAS, FTP
  • Power Supply: IEEE802.3af PoE, 12VDC ±10%
  • Power Consumption: <10W
  • Protection: IP67 weatherproof, 4000V lightning protection
  • Operating Environment: -20°C ~ +60°C, 10–90% RH

Got Application Customization Questions?

• • Chat With One Of Our Qualified Agents online between the hours of 9:00Am – 5:00Pm CST
  • Email our Sales Department to get an answer within 24-hours
  • Contact Sales By Phone between the hours of 9:00Am – 5:00Pm to get instant recommendation

Included Items & Accessories

• • 1 Dual-lens Camera
  • 1 Accessory bag
  • Mounting Accessories
  • Instructions & Manual

Manufacturer Warranty

• • 2 Year System & Hardware Limited Warranty
