5X Optical Zoom 8MP Mini PTZ Dome IP Camera

8MP VCA AI Face Detection 5X Zoom PTZ Dome Camera – 4K Ultra HD, Smart Human & Vehicle Detection, Auto Tracking, Two-Way Audio, and IP67 Outdoor Housing

The FIRM3 5X Optical Zoom 8MP Mini PTZ Dome IP Camera delivers cutting-edge surveillance with AI-powered video analytics and crystal-clear 4K Ultra HD imaging. Powered by a 1/2.8″ Sony CMOS sensor, it outputs 3840 × 2160P resolution with excellent low-light performance (0.01 Lux), ensuring sharp video quality day or night.

With its 2.7–13.5mm motorized autofocus lens, the camera provides a 5X optical zoom range, enabling operators to shift from wide coverage to detailed close-up monitoring. 350° horizontal rotation and 87° vertical tilt with a 50°/s rotation speed make it ideal for dynamic, real-time monitoring of open areas such as parking lots, campuses, industrial sites, and public spaces.

This PTZ dome camera integrates AI video analytics, including face detection, human & vehicle detection, line crossing, intrusion, and perimeter protection. With human detection tracking and patrol functionality, it can automatically follow moving objects while simultaneously managing up to 16 target detections at once.

Features 2.7–13.5mm motorized autofocus lens – 5X optical zoom range – 350° horizontal rotation and 87° vertical tilt with a 50°/s rotation speed – face detection, human & vehicle detection

The dual-light system includes 8pcs array IR LEDs that provide 30–40m IR range, ensuring reliable night vision. Built-in two-way audio with microphone and speaker allows real-time communication and proactive deterrence with voice sirens and white LED flash alarms.

Connectivity is versatile with RTSP and ONVIF 23.12 compliance, ensuring integration with most NVRs and VMS platforms. Remote access is supported through multi-browser viewing, Windows/Mac PC client, and mobile apps (iOS/Android). Storage options include MicroSD (up to 512GB), FTP, NAS, or email snapshots.

With PoE+ (48V) or 12VDC power supply, <5W power consumption, 4000V lightning protection, and IP67-rated weatherproof housing, this dome camera is built for reliable outdoor surveillance in all weather conditions.

Key Features

• • 4K Ultra HD Resolution: 8MP (3840 × 2160P) video output.
  • AI Video Analytics: Face detection, human/vehicle detection, line crossing, intrusion, and perimeter protection.
  • 5X Optical Zoom: Motorized 2.7–13.5mm autofocus lens.
  • PTZ Coverage: 350° horizontal, 87° vertical, 50°/s rotation speed.
  • IR Night Vision: 8pcs array IR LEDs, 30–40m IR distance.
  • Low Light Imaging: 0.01 Lux sensitivity, Day/Night ICR, WDR, 2D/3D-DNR, BLC, HLC, Defog.
  • Smart Tracking & Patrol: Human detection auto-tracking, up to 255 presets, patrol mode.
  • Simultaneous Multi-Target: Detects up to 16 objects at once.
  • Two-Way Audio: Built-in microphone & speaker with siren and voice alarm deterrence.
  • Alarm Actions: Snapshot, recording, white LED flash, email, FTP, NAS storage.
  • Compression & Streaming: H.265/H.264 dual-stream, RTSP, ONVIF 23.12.
  • Remote Access: PC client, mobile app (Android/iOS), multi-browser support (IE/Chrome/Firefox/Edge/Safari).
  • Storage Options: MicroSD up to 512GB, NVR, NAS, FTP, email.
  • Rugged Outdoor Design: IP67 weatherproof housing with 4000V lightning protection.
  • Energy Efficient: Low power consumption <5W.
  • Power Options: IEEE802.3af PoE+ (48V) or 12VDC ±10% / 3A.
  • Operating Environment: -30°C to +60°C, 10–90% RH non-condensing.

Device Specification

• • Image Sensor: 1/2.8″ Sony CMOS, 8MP
  • Resolution: 3840 × 2160P (4K Ultra HD)
  • Illumination: 0.01 Lux, 0 Lux with IR
  • Lens: 2.7–13.5mm motorized autofocus, 5X optical zoom
  • Field of View: 87° (wide) – narrower at zoom
  • PTZ Range: Pan: 350° | Tilt: 87° | Speed: 50°/s
  • Smart AI Functions: Face detection, human & vehicle detection, line crossing, intrusion, perimeter protection, motion detection, privacy mask
  • IR System: 8pcs array IR LEDs | Distance: 30–40m
  • Audio: Two-way audio (mic + speaker), G.711u/a, AAC, PCM, AEC noise reduction
  • Alarm Functions: White LED flash, voice siren, snapshot, relay, email/FTP/NAS storage
  • Streaming:
    • Mainstream: 4K @20fps; 6MP/5MP/4MP/1080P/720P @30fps
    • Sub-stream: VGA/360P/QVGA @30fps
    • Third stream: 1080P/720P/CIF @10fps
  • Compression: H.265/H.264 dual-stream
  • Network: RJ45 100Mbps, ONVIF 23.12, RTSP, HTTP/HTTPS, FTP, SMTP, DHCP, NTP, RTP/RTMP, IPv4/IPv6, P2P, HiK
  • Storage: MicroSD (up to 512GB), NVR, NAS, FTP
  • Protection: IP67 weatherproof, 4000V lightning protection
  • Power Supply: IEEE802.3af PoE+ (48V), 12VDC ±10% / 3A
  • Power Consumption: <5W
  • Operating Conditions: -30°C ~ +60°C, 10–90% RH non-condensing

Got Application Customization Questions?

• • Chat With One Of Our Qualified Agents online between the hours of 9:00Am – 5:00Pm CST
  • Email our Sales Department to get an answer within 24-hours
  • Contact Sales By Phone between the hours of 9:00Am – 5:00Pm to get instant recommendation

Included Items & Accessories

• • 1 Dome PTZ camera
  • 1 Accessory bag
  • Mounting Accessories
  • Instructions & Manual

Manufacturer Warranty

• • 2 Year System & Hardware Limited Warranty
